HPE Aruba AP-574 (US)


MSRP€2,299.00
€1,774.00
HPE Aruba AP-574 (US)

Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • Wireless access point
  • ZigBee, 802.11ac Wave 2, Bluetooth 5.0, 802.11ax
  • ZigBee, Bluetooth, Wi-Fi
  • Dual Band
HPE Aruba AP-574 (US)
  • Wireless access point
  • ZigBee, 802.11ac Wave 2, Bluetooth 5.0, 802.11ax
  • ZigBee, Bluetooth, Wi-Fi
  • Dual Band
  Additional Details
Price: €1,774.00
MSRP: €2,299.00
Mfr Part #: R4H13A
SHI Part #: 40031338
Category: Cellular wireless base stations
UNSPSC: 43222631
Manufacturer: Hewlett Packard Enterprise
Product Type: Hardware
Product Line: HPE - Networking
General Information
CategoryCellular wireless base stations
DescriptionHPE Aruba AP-574 (US) - Wireless access point - ZigBee, 802.11ac Wave 2, Bluetooth 5.0, 802.11ax - ZigBee, Bluetooth, Wi-Fi - Dual Band
ManufacturerHewlett Packard Enterprise
MSRP€2,299.00
UNSPSC43222631
Main Specifications
Dimensions & Weight / Depth24 cm
Dimensions & Weight / Height19 cm
Dimensions & Weight / Weight2.7 kg
Dimensions & Weight / Width24 cm
Header / BrandAruba
Miscellaneous / Product ColorSilver
Networking / Connectivity TechnologyWireless
Networking / Data Link Protocol
  • 802.11ax
  • Bluetooth 5.0
  • IEEE 802.11a
  • IEEE 802.11ac Wave 2
  • IEEE 802.11ax (Wi-Fi 6)
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n
  • ZigBee
Networking / Form FactorExternal
Networking / TypeWireless access point
Packaged Quantity1
Service & Support / TypeLimited lifetime warranty
Antenna
AntennaInternal
Antenna Qty1
DirectivityOmni-directional
Environmental Parameters
Humidity Range Operating5 - 93% (non-condensing)
Max Operating Temperature65 °C
Min Operating Temperature-40 °C
Expansion / Connectivity
Interfaces
  • 1 x HPE Smart Rate - RJ-45
  • 1 x 1000Base-T - RJ-45
  • 1 x console - USB-C
  • Antenna - N connector x 4
  • Antenna - N connector x 2
General
Depth24 cm
Device TypeWireless access point
Height19 cm
Ruggedized DesignOutdoor
Weight2.7 kg
Width24 cm
Internet of Things (IoT)
Communications TechnologyBluetooth Low Energy (LE), Zigbee
Internet of Things (IoT) CompatibleYes
Manufacturer Warranty
Service & SupportLimited warranty - lifetime
Miscellaneous
Compliant StandardsCB, UL 2043, FCC, EN 60601-1-2, cTUVus, IP67, IP66, EN 60601-1-1, EMC 2014/30/EU, ISED, IEC/EN/UL 60950, ETSI 300 019-2-4, RED 2014/53/EU
Networking
CapacityWireless clients per Wi-Fi radio: 512
Compliant StandardsIEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, IEEE 802.3bz, IEEE 802.11ax, Wi-Fi CERTIFIED 6
Connectivity TechnologyWireless
Data Link ProtocolIEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Encryption AlgorithmWPA2, WPA3-Enhanced Open
FeaturesDFS support, WLAN controller mode, WPA2 encryption, Trusted Platform Module (TPM), Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Direct Sequence Spread Spectrum (DSSS), Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Virtual Mobility Controller mode, Advanced Cellular Coexistence (ACC), ClientMatch, cyclic shift diversity (CSD), Green AP technology, MU-MIMO technology, remote VPN tunnel mode, Air Monitor (AM), Intelligent Power Monitoring (IPM), Zero-touch provisioning (ZTP), 4x4 MU-MIMO technology, Aruba AirMatch, Orthogonal Frequency Division Multiple Access (OFDMA), Target Wait Time (TWT)
Form FactorExternal
Frequency Band2.4 GHz, 5 GHz
Line Coding FormatCCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, 1024 QAM, OFDMA
Spread Spectrum MethodDSSS, OFDMA
Status IndicatorsSystem, status
