HPE Modular Smart Array 2060 16Gb Fibre Channel SFF Flash Bundle
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
HPE Modular Smart Array 2060 16Gb Fibre Channel SFF Flash Bundle
- Solid state drive array
- 12 TB
- 24 bays (SAS-3)
- SSD 960 GB x 12
- 16Gb Fibre Channel (external)
- rack-mountable
- 2U
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | S2E37B |
| SHI Part #: | 47017677 |
| Category: | Disk arrays |
| UNSPSC: | 43201802 |
| Manufacturer: | Hewlett Packard Enterprise |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Disk arrays |
| Description | HPE Modular Smart Array 2060 16Gb Fibre Channel SFF Flash Bundle - Solid state drive array - 12 TB - 24 bays (SAS-3) - SSD 960 GB x 12 - 16Gb Fibre Channel (external) - rack-mountable - 2U |
| Manufacturer | Hewlett Packard Enterprise |
| UNSPSC | 43201802 |
| Main Specifications | |
| Dimensions & Weight / Depth | 50.8 cm |
| Dimensions & Weight / Height | 8.9 cm |
| Dimensions & Weight / Weight | 5 kg |
| Dimensions & Weight / Width | 44.5 cm |
| Hard Drive / Capacity | 960 GB |
| Hard Drive / Interface | Serial Attached SCSI 3 |
| Hard Drive / Interface Type | Serial Attached SCSI 3 |
| Header / Brand | HPE |
| Miscellaneous / Product Color |
|
| Packaged Quantity | 1 |
| Service & Support / Type | 3-year warranty |
| Storage / HDD Array External Interface | 16Gb Fibre Channel |
| Storage / HDD Array External Interface Class | Fibre Channel |
| Storage / Rack-mountable | Rack-mountable |
| Storage / Total Array Capacity |
|
| Storage / Type | Solid state drive array |
| Chassis | |
| Installed Devices / Modules Qty | 12 |
| Supported Devices / Modules Qty | 24 |
| Supported Drives | SAS-3 |
| Dimensions & Weight | |
| Depth | 50.8 cm |
| Height | 8.9 cm |
| Weight | 5 kg |
| Width | 44.5 cm |
| Environmental Parameters | |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 5 °C |
| Sound Emission | 74 dBA |
| Environmental Standards | |
| ENERGY STAR Certified | Yes |
| Expansion / Connectivity | |
| Expansion Bays | 24 (total) / 12 (free) - 2.5" SFF |
| Interfaces |
|
| General | |
| Device Type | Solid state drive array |
| Enclosure Type | Rack-mountable - 2U |
| Hard Drive | |
| Capacity | 12 x 960 GB |
| Features | Read Intensive |
| Interface Type | SAS 12Gb/s |
| Type | SSD |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts - 3 years |
| Miscellaneous | |
| Features | SNMP support, SMTP support |
| Included Accessories | Rack mounting kit |
| Power | |
| Max Supported Qty | 2 |
| Power Device | 2 x internal power supply - hot-plug |
| Power Provided | 764 Watt |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Processor | |
| CPU | No CPU |
| Storage | |
| HDD Array External Interface | 16Gb Fibre Channel |
| Max Supported Capacity | 184.32 TB |
| Maximum LUNs | 512 |
| Total Array Capacity | 12 TB |
| Storage Controller | |
| Cache / Buffer Size (Max) | 24 GB |
| Data Transfer Rate | 1.2 GBps |
| Installed Qty | 2 |
| Interface Type | SAS 12Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
| Type | RAID (16Gb Fibre Channel) |
| Storage Controller (2nd) | |
| Installed Qty | 2 |
| System Requirements | |
| OS Required | Red Hat Linux 8.0, Microsoft Windows Server 2012, Microsoft Windows Server 2016, VMware vSphere 6.7 (ESXi), Microsoft Windows Server 2019, SUSE Linux Enterprise Server 15, Microsoft Windows Server 2022 |
