Samsung 750 EVO MZ-750500
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Samsung 750 EVO MZ-750500
- SSD
- encrypted
- 500 GB
- internal
- 2.5"
- SATA 6Gb/s
- buffer: 512 MB
- 256-bit AES
- Self-Encrypting Drive (SED), TCG Opal Encryption 2.0
| Additional Details | |
|---|---|
| Mfr Part #: | MZ-750500BW |
| SHI Part #: | 40687307 |
| Category: | Hard drives |
| UNSPSC: | 43201803 |
| Manufacturer: | Samsung |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Hard drives |
| Description | Samsung 750 EVO MZ-750500 - SSD - encrypted - 500 GB - internal - 2.5" - SATA 6Gb/s - buffer: 512 MB - 256-bit AES - Self-Encrypting Drive (SED), TCG Opal Encryption 2.0 |
| Manufacturer | Samsung |
| UNSPSC | 43201803 |
| Main Specifications | |
| Environmental Parameters | |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Shock Tolerance (non-operating) | 1500 g @ 0.5 ms |
| Expansion & Connectivity | |
| Compatible Bay | 2.5" |
| Interfaces | 1 x SATA 6 Gb/s - 7 pin Serial ATA |
| General | |
| Buffer Size | 512 MB |
| Capacity | 500 GB |
| Depth | 100 mm |
| Device Type | Solid state drive - internal |
| Encryption Algorithm | 256-bit AES |
| Features | Hardware Full Disk Encryption (FDE), TRIM support, sleep mode, DDR3 DRAM Cache, Auto Garbage Collection Algorithm, Worldwide Name (WWN), RAPID mode support, TurboWrite Technology, Samsung MGX Controller, S.M.A.R.T., IEEE 1667 |
| Form Factor | 2.5" |
| Hardware Encryption | Yes |
| Height | 6.8 mm |
| Interface | SATA 6Gb/s |
| Weight | 50 g |
| Width | 69.85 mm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Performance | |
| Drive Transfer Rate | 600 MBps (external) |
| Internal Data Rate | 540 MBps (read) / 520 MBps (write) |
| Maximum 4KB Random Read | 98000 IOPS |
| Maximum 4KB Random Write | 88000 IOPS |
| SSD Endurance | 100 TB |
| Power | |
| Power Consumption |
|
| Reliability | |
| MTBF | 1,500,000 hours |
| Software & System Requirements | |
| Software Included | Samsung Magician Software |
