APC Easy UPS SRV SRVPM1KIL
MSRP€399.99
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
APC Easy UPS SRV SRVPM1KIL
- UPS
- AC 220/230/240 V
- 800 Watt
- 1000 VA
- no battery
- USB, RS-232
- output connectors: 3
- PFC
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | €399.99 |
| Mfr Part #: | SRVPM1KIL |
| SHI Part #: | 37323022 |
| Category: | Power conditioning equipment |
| UNSPSC: | 39121000 |
| Manufacturer: | APC by Schneider Electric |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Power conditioning equipment |
| Description | APC Easy UPS SRV SRVPM1KIL - UPS - AC 220/230/240 V - 800 Watt - 1000 VA - no battery - USB, RS-232 - output connectors: 3 - PFC |
| Manufacturer | APC by Schneider Electric |
| MSRP | €399.99 |
| UNSPSC | 39121000 |
| Main Specifications | |
| Dimensions & Weight / Depth | 28.8 cm |
| Dimensions & Weight / Height | 22.3 cm |
| Dimensions & Weight / Weight | 9.3 kg |
| Dimensions & Weight / Width | 14.5 cm |
| Header / Brand | APC |
| Miscellaneous / Product Color | Black |
| Networking / Remote Management Interface |
|
| Packaged Quantity | 1 |
| Power Device / Form Factor | External |
| Power Device / Output Connector Qty | 3 |
| Power Device / Power Capacity (VA) | 1000 VA |
| Power Device / UPS Technology | On-line |
| Power Device / Voltage Required | AC 220/230/240 V |
| Product Type | UPS |
| Service & Support / Type | 2-year warranty |
| Battery | |
| Type | No battery |
| Dimensions & Weight | |
| Depth | 28.8 cm |
| Height | 22.3 cm |
| Weight | 9.3 kg |
| Width | 14.5 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 36.5 cm |
| Shipping Height | 33 cm |
| Shipping Weight | 10.6 kg |
| Shipping Width | 23.5 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x SmartSlot |
| Interfaces |
|
| General | |
| Device Type | UPS - Power Factor Correction (PFC) - external |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | USB cable - external |
| Compliant Standards | IEC 62040-1-1, IEC 62040-1-2, RoHS, REACH |
| Features | LCD display, internal bypass, Eco-Mode, auto restart, audible alarm, automatic self-test, double conversion, generator compatible, LED indicators |
| Networking | |
| Remote Management Interface | USB, RS-232 |
| Power Device | |
| Circuit Protection | Circuit breaker |
| Frequency Provided | 50/60 Hz ± 3Hz |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x power IEC 60320 C14 |
| Input Voltage | AC 220/230/240 V |
| Input Voltage Range | AC 160 - 280 V |
| Output Voltage | AC 220/230/240 V ± 3% - 50/60 Hz |
| Output Waveform | Sinewave |
| Power Capacity | 800 watt / 1000 VA |
| Power Output Connectors Details | 3 x power IEC 60320 C13 |
| Surge Energy Rating | 600 joules |
| Surge Suppression | Yes |
| UPS Technology | On-line |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
