HPE ProLiant DL325 Gen11
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
HPE ProLiant DL325 Gen11
- Server
- rack-mountable 1U
- 1-way
- 1 x EPYC 9124 / up to 3.7 GHz
- RAM 32 GB
- SATA/SAS/NVMe
- hot-swap 2.5" bay(s)
- no HDD
- Gigabit Ethernet
- monitor: none
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | P66775-B21 |
| SHI Part #: | 46859225 |
| Category: | Rack systems for rack mount electroni... |
| UNSPSC: | 24102001 |
| Manufacturer: | Hewlett Packard Enterprise |
| Product Type: | Hardware |
Audio/Video Cables
- Storage cable kit
- x2 OCP Tri-Mode
- for ProLiant DL325 Gen11, DL345 Gen11, DL365 Gen11, DL385 Gen11
CPU Processors
- 24-core
- 48 threads
- 128 MB cache
- Socket SP5
- for ProLiant DL325 Gen11, DL345 Gen11, DL385 Gen11
- 48-core
- 96 threads
- 256 MB cache
- Socket SP5
- for ProLiant DL325 Gen11, DL345 Gen11
- 24-core
- 48 threads
- 256 MB cache
- Socket SP5
- for ProLiant DL325 Gen11, DL345 Gen11, DL385 Gen11
| General Information | |
|---|---|
| Category | Rack systems for rack mount electroni... |
| Description | HPE ProLiant DL325 Gen11 - Server - rack-mountable 1U - 1-way - 1 x EPYC 9124 / up to 3.7 GHz - RAM 32 GB - SATA/SAS/NVMe - hot-swap 2.5" bay(s) - no HDD - Gigabit Ethernet - monitor: none |
| Manufacturer | Hewlett Packard Enterprise |
| UNSPSC | 24102001 |
| Main Specifications | |
| Chassis / Form Factor | Rack-mountable |
| Chassis / Server Storage Bays | Hot-swap |
| Chassis / Server Swappable Drive Interface | SATA/SAS/NVMe |
| Dimensions & Weight / Depth | 64.94 cm |
| Dimensions & Weight / Height | 4.29 cm |
| Dimensions & Weight / Weight | 12.56 kg |
| Dimensions & Weight / Width | 43.46 cm |
| Display / Type | None. |
| Header / Brand | HPE |
| Header / Country Kits | Worldwide |
| Miscellaneous / Product Color |
|
| Networking / Data Link Protocol | Gigabit Ethernet |
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 3 GHz |
| Processor / Manufacturer | AMD |
| Processor / Number of Cores | 16-core |
| Processor / Processor Number | 9124 |
| Processor / Type | EPYC |
| RAM / Form Factor | DIMM 288-pin |
| RAM / Memory Speed | 4800 MHz |
| RAM / Technology | DDR5 SDRAM |
| Service & Support / Type | 3-year warranty |
| System / Hard Drive Capacity | 0 GB |
| System / Type | Server |
| Cache Memory | |
| Cache Per Processor | 64 MB |
| Installed Size | L3 cache - 64 MB |
| Dimensions & Weight | |
| Depth | 64.94 cm |
| Height | 4.29 cm |
| Weight | 12.56 kg |
| Width | 43.46 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 91.6 cm |
| Shipping Height | 24.2 cm |
| Shipping Width | 60 cm |
| Environmental Parameters | |
| Humidity Range Operating | 8 - 90% RH (non-condensing) |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 10 °C |
| Expansion / Connectivity | |
| Bays | 8 (total) / 8 (free) x hot-swap 2.5" SFF |
| Interfaces |
|
| Slots | 1 (total) / 1 (free) x PCIe 5.0 x16 (x16 mode) |
| General | |
| Hot-Swap Bays Qty | 8 |
| Localization | Region: Worldwide |
| Product Form Factor | Rack-mountable - 1U |
| Server Scalability | 1-way |
| Type | Server |
| Graphics Controller | |
| Video Interfaces | VGA |
| Video Memory | 16 MB |
| Hard Drive | |
| Type | No HDD |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years - on-site - response time: next business day |
| Miscellaneous | |
| Compliant Standards | AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1, Redfish API, SMBIOS 3.1, ErP Lot 9 |
| Included Accessories | 7 x standard fans |
| Monitor | |
| Monitor Type | None. |
| Networking | |
| Data Link Protocol | Gigabit Ethernet |
| Ethernet Controller | Broadcom BCM57416 |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Features | Wake on LAN (WoL), PXE support |
| Interface (Bus) Type | Open Compute Project mezzanine (OCP) 3.0 |
| Remote Management Controller | Integrated Lights-Out 6 |
| Remote Management Protocol | SNMP 3, IPMI 2.0 |
| Operating System / Software | |
| OS Certified | CentOS, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, SuSE Linux Enterprise Server 12 SP3, Red Hat Enterprise Linux 7.4, Red Hat Enterprise Linux 7.5, VMware vSphere 6.5 (ESXi) Update 2, VMware vSphere 6.7 (ESXi) |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| Device Type | Power supply - hot-plug |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Provided | 800 Watt |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Voltage Required | AC 100-120/200-240 V (50/60 Hz) |
| Processor / Chipset | |
| Clock Speed | 3 GHz |
| CPU | AMD EPYC 9124 |
| CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| Max CPU Qty | 1 |
| Max Turbo Speed | 3.7 GHz |
| Number of Cores | 16-core |
| RAM | |
| Configuration Features | 1 x 32 GB |
| Effective Memory Speed | 4800 MHz |
| Features | Registered, HPE SmartMemory |
| Form Factor | DIMM 288-pin |
| Installed Size | 32 GB (installed) / 3 TB (max) |
| Rated Memory Speed | 4800 MHz |
| Slots | 12 (total) / 11 (empty) |
| Technology | DDR5 SDRAM |
| Storage Controller | |
| Buffer Size | 4 GB |
| Channel Qty | 8 |
| Controller Interface Type | Serial ATA-600 / SAS 3.0 / PCI Express (NVMe) |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| Storage Controller Name | HPE MR408i-o Gen11 SPDM |
| Type | 1 x RAID - OCP |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 3.0 |
