GALAXY VS UPS 30KW 208V, 3 INTERNAL 9AH SMART MODULAR BATTERY STRINGS, EXPANDABL


MSRP€41,515.00
€24,353.00
GALAXY VS UPS 30KW 208V, 3 INTERNAL 9AH SMART MODULAR BATTERY STRINGS, EXPANDABL

Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
GALAXY VS UPS 30KW 208V, 3 INTERNAL 9AH SMART MODULAR BATTERY STRINGS, EXPANDABL
  Additional Details
Price: €24,353.00
MSRP: €41,515.00
Mfr Part #: GVSUPS30KB5FS
SHI Part #: 40088617
Category: Uninterruptible power supplies
UNSPSC: 39121011
Manufacturer: APC
Product Type: Hardware
Product Line: APC by Schneider Electric
General Information
CategoryUninterruptible power supplies
DescriptionGALAXY VS UPS 30KW 208V, 3 INTERNAL 9AH SMART MODULAR BATTERY STRINGS, EXPANDABL
ManufacturerAPC
MSRP€41,515.00
UNSPSC39121011
Main Specifications
Dimensions & Weight / Depth84.7 cm
Dimensions & Weight / Height197 cm
Dimensions & Weight / Weight665 kg
Dimensions & Weight / Width55 cm
General / SubcategoryUPS
Header / BrandSchneider
Miscellaneous / Product ColorWhite
Packaged Quantity1
Power Device / Form FactorExternal
Power Device / Power Capacity (VA)30000 VA
Power Device / UPS TechnologyOn-line
Power Device / Voltage RequiredAC 200/208/220 V
Product TypeUPS
Service & Support / Type1-year warranty
Battery
Capacity9 Ah
Quantity3 battery strings
TechnologyLead acid
Voltage Provided480 V
Dimensions & Weight
Depth84.7 cm
Height197 cm
Weight665 kg
Width55 cm
Dimensions & Weight (Shipping)
Shipping Depth101 cm
Shipping Height208.2 cm
Shipping Weight690 kg
Shipping Width75.5 cm
Environmental Parameters
Humidity Range Operating0 - 95% (non-condensing)
Max Operating Temperature40 °C
Min Operating Temperature0 °C
Sound Emission54 dBA
General
Bundled ServicesStart-Up Service 5X8
ColorWhite, RAL 9003
Device TypeUPS - external
Manufacturer Warranty
Service & SupportLimited warranty - 1 year - on-site
Miscellaneous
Compliant StandardsFCC Part 15 A, EN 62040-2, CSA C22.2 No. 107.3, IP20, EN 62040-3, EN 62040-1, OSHPD, UL 1778 5th edition
FeaturesLCD display, built-in static bypass, overload protection
Power Device
Efficiency94% at 100% Load, 94.5% at 75% Load, 93.2% at 25% Load, 94.6% at 50% Load
Frequency Provided50/60 Hz ± 0.1%
Frequency Required40 - 70 Hz
Input VoltageAC 200/208/220 V
Input Voltage RangeAC 177 - 239 V
Input Wiring3-phase
Max Spike Current65000 A
Output VoltageAC 200/208/220 V ± 5% - 50/60 Hz
Output WaveformSinewave
Power Capacity30 kW / 30000 VA
Power Factor (PF)0.99
UPS TechnologyOn-line
