USV / Symmetra PX 48kW / All-in-One-Frame / 400V
MSRP€21,500.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
USV / Symmetra PX 48kW / All-in-One-Frame / 400V
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | €21,500.00 |
| Mfr Part #: | SYCF48KH |
| SHI Part #: | 18199959 |
| Category: | Uninterruptible power supplies |
| UNSPSC: | 39121011 |
| Manufacturer: | APC by Schneider Electric |
| Product Type: | Other |
| General Information | |
|---|---|
| Category | Uninterruptible power supplies |
| Description | USV / Symmetra PX 48kW / All-in-One-Frame / 400V |
| Manufacturer | APC by Schneider Electric |
| MSRP | €21,500.00 |
| UNSPSC | 39121011 |
| Main Specifications | |
| Dimensions & Weight / Depth | 107 cm |
| Dimensions & Weight / Height | 199 cm |
| Dimensions & Weight / Weight | 307 kg |
| Dimensions & Weight / Width | 60 cm |
| General / Subcategory | UPS |
| Header / Brand | APC |
| Packaged Quantity | 1 |
| Power Device / Form Factor | External |
| Power Device / Output Connector Qty | 1 |
| Power Device / Power Capacity (VA) | 48000 VA |
| Power Device / UPS Technology | On-line |
| Power Device / Voltage Required | AC 380/400/415 V |
| Product Type | UPS |
| Service & Support / Type | 1-year warranty |
| Dimensions & Weight | |
| Depth | 107 cm |
| Height | 199 cm |
| Weight | 307 kg |
| Width | 60 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 121 cm |
| Shipping Height | 214 cm |
| Shipping Weight | 331 kg |
| Shipping Width | 84.8 cm |
| Environmental Parameters | |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Expansion / Connectivity | |
| Expansion Slots | 2 SmartSlot |
| Interfaces | 1 x EPO (emergency power off) |
| General | |
| Device Type | UPS - external |
| Height (Rack Units) | 42U |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Compliant Standards | FCC Class A certified, FCC Part 15, IEC 62040-3, IEC 62040-1-1, EN 50091-1 |
| Features | Audible alarm, emergency power off, LCD display, built-in static bypass |
| Power Device | |
| Circuit Protection | Circuit breaker |
| Frequency Provided | 50/60 Hz |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x hardwire 5-wire (3PH + N + G) |
| Input Voltage | AC 380/400/415 V |
| Input Voltage Margin | ± 5% |
| Input Voltage Range | AC 340 - 477 V |
| Input Wiring | 3-phase |
| Output Voltage | AC 380/400/415 V ± 2% - 50/60 Hz |
| Output Waveform | Sinewave |
| Power Capacity | 48 kW / 48000 VA |
| Power Output Connectors Details | 1 x hardwire 5-wire (3PH + N + G) |
| UPS Technology | On-line |
