APC Smart-UPS 1000VA XL USB & Serial


MSRP€1,350.00
€1,262.00
APC Smart-UPS 1000VA XL USB & Serial

Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • UPS
  • AC 230 V
  • 1000 VA
  • output connectors: 8
  • black
APC Smart-UPS 1000VA XL USB & Serial
  • UPS
  • AC 230 V
  • 1000 VA
  • output connectors: 8
  • black
  Additional Details
Price: €1,262.00
MSRP: €1,350.00
Mfr Part #: SUA1000UXI
SHI Part #: 14868438
Category: Uninterruptible power supplies
UNSPSC: 39121011
Manufacturer: APC
Product Type: Hardware
Product Line: APC by Schneider Electric

Audio/Video Cables

APC - Serial cable - RJ-45 (M) to DB-9 (F)
  • 2 m
  • for P/N: SRV1KA-TW, SRV1KI-TW, SRV2KA-TW, SRV2KI-TW, SRV3KA-TW, SRV3KI-TW, SRV6KI-TW
MSRP €40.00 €33.00
APC - Power cable kit
  • power IEC 60320 C13 to IEC 60320 C14
  • 10 A
  • 1.2 m
  • red
  • for P/N: SCL500RMI1UC, SCL500RMI1UNC, SMT3000I-AR, SMT3000R2I-AR, SMTL750RMI2UC, SRT1500RMXLI
€113.00
APC - Power cable - power IEC 60320 C13 locking to IEC 60320 C14 locking
  • 60 cm
  • red (pack of 6)
  • for P/N: SCL500RMI1UC, SCL500RMI1UNC, SMT3000I-AR, SMT3000R2I-AR, SMTL750RMI2UC, SRT1500RMXLI
€74.00

Control/Interface Boards

APC SmartSlot Triple Chassis
  • System bus extender
  • for P/N: G3H10K3IM6X710, G3H10K3IM9X710, SRC1KI, SYA8K16PX798, SYA8K16PXRX798, SYA8K8PX798
MSRP €593.00 €383.00
APC Isolate UPS Extension Cable
  • Serial port extender
  • up to 100 m
  • for P/N: SRV1KA-TW, SRV1KI-TW, SRV2KA-TW, SRV2KI-TW, SRV3KA-TW, SRV3KI-TW, SRV6KI-TW
€261.00
General Information
CategoryUninterruptible power supplies
DescriptionAPC Smart-UPS 1000VA XL USB & Serial - UPS - AC 230 V - 1000 VA - output connectors: 8 - black
ManufacturerAPC
MSRP€1,350.00
UNSPSC39121011
Main Specifications
Dimensions & Weight / Depth44 cm
Dimensions & Weight / Height22 cm
Dimensions & Weight / Weight13 kg
Dimensions & Weight / Width17 cm
General / SubcategoryUPS
Header / BrandAPC
Miscellaneous / Product ColorBlack
Packaged Quantity1
Power Device / Form FactorExternal
Power Device / Output Connector Qty8
Power Device / Power Capacity (VA)1000 VA
Power Device / UPS TechnologyLine interactive
Power Device / Voltage RequiredAC 230 V
Product TypeUPS
Service & Support / Type2-year warranty
Dimensions & Weight
Depth44 cm
Height22 cm
Weight13 kg
Width17 cm
Environmental Parameters
Humidity Range Operating0 - 95%
Humidity Range Storage0 - 95%
Max Operating Temperature40 °C
Max Storage Temperature45 °C
Min Operating Temperature0 °C
Min Storage Temperature-15 °C
Expansion / Connectivity
Expansion Slots1 (total) / 1 (free) x SmartSlot
Interfaces
  • 1 x USB - 4 pin USB Type B
  • 1 x management (RS-232) - 9 pin D-Sub (DB-9)
General
ColorBlack
Device TypeUPS - external
Manufacturer Warranty
Service & SupportLimited warranty - replacement - 2 years
Miscellaneous
Cables Included
  • Serial cable - external
  • Power cable - external - 1.8 m
Compliant StandardsC-Tick, GOST, PCBC, UL 1449, VDE
FeaturesAudible alarm
Power Device
Frequency Required50/60 Hz
Input Connectors1 x power IEC 60320 C14
Input VoltageAC 230 V
Input Voltage RangeAC 160 - 285 V
Input Voltage Range (Adjustable)AC 151 - 302 V
Output VoltageAC 220/230/240 V
Output WaveformSinewave
Power Capacity1000 VA
Power Output Connectors Details8 x power IEC 60320 C13
Supported Battery TechnologyLead acid
Surge Energy Rating480 Joules
Surge SuppressionYes
UPS TechnologyLine interactive
Software / System Requirements
Software IncludedDrivers & Utilities, APC PowerChute Smart-UPS Bundle
